Default Progress on the Treit and Davenport liner

It's that time again. There's a new update on the server:

http://www.target550.com/gallery/33_...nel/index.html

Some of the items touched on in this update include the rear wheel enclosures:



and the plenum and ducting between the blower and intake manifold:



finally, the instrument panel got a bit of milling to fit it to the shape of the body panels.



While all of Freud's shots are great, I found those that show the ducting and plenum between the blower and intake manifold to be an indication that the light at the end of the tunnel is getting closer and brighter.

Enjoy,
