Technical Multi Carb Setups -Let's see 'em!

Discussion in 'The Hokey Ass Message Board' started by pkhammer, Apr 11, 2020.

  1. indianmark
    Joined: Oct 18, 2007
    Posts: 176

    indianmark
    Member
    from new jersey

    Cragar intake with 97's and straight linkage on a 56 354 in a 31 Plymouth PA

    pkhammer likes this.
  2. johnnymac1
    Joined: Sep 16, 2012
    Posts: 129

    johnnymac1
    Member

    My triplets, large logo Holley bowls,

  3. rbrewer
    Joined: Mar 16, 2011
    Posts: 84

    rbrewer
    Member

    My Offenhauser 4 x 2 with Roch. 2 GV's (SBC) , special thanks to Tim Bowman at Old School Induction!, This for a future project (tbd).


    Attached Files:

  4. ramblin dan
    Joined: Apr 16, 2018
    Posts: 2,038

    ramblin dan

  5. BigRRR
    Joined: Sep 5, 2019
    Posts: 7

    BigRRR

    6-97's 371 Olds in my 50 Merc!!!
    Mercury 7.jpg Mercury 6.jpg

  6. Well I missed out on this one, drug my feet contacting the seller, looks like I'll keep my 2x4's on the T Screenshot_20200415-223944_Facebook.jpg

    TBirdGirl26, Stebo27, Deuces and 6 others like this.
  7. 2OLD2FAST
    Joined: Feb 3, 2010
    Posts: 2,355

    2OLD2FAST
    Member
    from illinois

    Dummy carbs (sigh) , an insult to hotrodders everywhere....

  8. Moriarity
    Joined: Apr 11, 2001
    Posts: 18,173

    Moriarity
    SUPER MODERATOR
    Staff Member

    sorry man, bone stock engine in a custom....

    LOST ANGEL likes this.
  9. 2OLD2FAST
    Joined: Feb 3, 2010
    Posts: 2,355

    2OLD2FAST
    Member
    from illinois

    Its kinda like the first time you took a " falsie" bra off a girl ....

    loudbang likes this.
  10. Jalopy Joker
    Joined: Sep 3, 2006
    Posts: 24,937

    Jalopy Joker
    Member

  11. Moriarity
    Joined: Apr 11, 2001
    Posts: 18,173

    Moriarity
    SUPER MODERATOR
    Staff Member

    can't say that that ever happened....to me... all the rest of my multi carb setups run all the carbs, If that one had a modified engine I may have made all the carbs work but honestly, I drive that car like an old man, low and slow.. My corvette on the other hand I drive like I don't have a nickel in it....

  12. slick36
    Joined: Oct 9, 2009
    Posts: 12

    slick36
    Member

  13. FrankenRodz
    Joined: Dec 20, 2007
    Posts: 891

    FrankenRodz
    Member

    Dual 2-Barrel Progressive Carter/Webbers on my '49 Chevy Styleline.


  14. ssracer
    Joined: May 2, 2011
    Posts: 106

    ssracer
    Member
    from oklahoma

    My 61 Buick with Gran Sport 2x4 setup IMG_1679.JPG IMG_1680.JPG

  15. jnaki
    Joined: Jan 1, 2015
    Posts: 4,509

    jnaki

    upload_2020-4-29_4-0-9.png April-May 1960 Lions Dragstrip
    Hello,

    Our multiple carb set up was first used on a 283 SBCwith 6 Strombergs on an old 60’s Weiand Manifold in March 1960. We bought the 283 long block from a tiny speed shop hidden in a residential area of Long Beach. (kind of like our own, small garage shop) We got the motor completely built with locally bought, speed stuff and put it into our 40 Willys coupe.

    With the 6 Strombergs fully adjusted, it ran well for a first time build. The light weight of the Willys, the 283 SBC with 6 Strombergs got put into the B/Gas class. It was competitive, but not against the top of the class. We were way off those top times and speeds. But, it was our first time build and racing adventure. It was fast for a street legal coupe, but not as fast as the top competitors at the time, Jr. Thompson, Doug Cook, K,S. Pittman, Al Hirshfield, etc.

    Then several months later, with more racing under our belts, we upgraded that same motor to a 292 c.i. (plus more internal blower grade speed stuff), went to a new Isky Gilmer 671 Belt Drive and the Edlebrock blower manifold for the 671 blower on this motor in May 1960.
    Since we could not afford the two port Hilborn Injectors at the time, the 6 Strombergs went on a new, flat Weiand manifold on top of the 671

    The initial tune up of the 6 Strombergs on the SBC was hectic, to say the least. Adjusting one carb was hard enough, let alone 5 more. But, let us just say that it took the longest of anything on the first time build. Once, it was adjusted, it made such a great sound when revved up. If you thought a single 4 barrel carb with the air cleaner removed made a sucking sound, 6 two barrels easily made more horsepower and a more powerful sound.

    Jnaki

    The crazy thing was that later on in the rebuild, when we put the fully adjusted, 6 Strombergs on top of the 671 blower, we thought they were already adjusted and should have run well on the start up… That was not the case. It must have taken us a few more tries to get everything in good working order for the drags. Who needed those fancy, expensive, two port Hilborn Injectors? These Strombergs worked well on top of the 671 and made it super powerful.
    upload_2020-4-29_4-1-51.png Similar 6 Stromberg carburetors on a different manifold for the new 292 c.i. blower grade SBC.


  16. 65pacecar
    Joined: Sep 22, 2010
    Posts: 1,939

    65pacecar
    Member
    from KY, AZ



    Sent from my iPhone using H.A.M.B.

  17. mgtstumpy
    Joined: Jul 20, 2006
    Posts: 8,056

    mgtstumpy
    Member

  18. bschwoeble
    Joined: Oct 20, 2008
    Posts: 551

    bschwoeble
    Member

    loudbang likes this.
  19. bschwoeble
    Joined: Oct 20, 2008
    Posts: 551

    bschwoeble
    Member

    OMG ! So many Fords without a Ford, Mopars without a Mopar. Didn't look to see if any GM without a GM. When will the rioting start ?

    1947knuck and loudbang like this.
  20. cruiserjohn76
    Joined: Apr 7, 2011
    Posts: 511

    cruiserjohn76
    ALLIANCE MEMBER

    My 56 324 Olds, three 94's. It's come along way since the last picture, should be running and driving in the next few months. IMG_2566.JPG IMG_2921.JPG

  21. Sonofabob
    Joined: Jan 28, 2020
    Posts: 68

    Sonofabob

  22. old.hot.rodder
    Joined: Oct 13, 2012
    Posts: 160

    old.hot.rodder
    Member

  23. Bandit Billy
    Joined: Sep 16, 2014
    Posts: 6,549

    Bandit Billy
    ALLIANCE MEMBER

    I ran into a little issue with my trio of 97's on the '34 that I thought might fit well in this thread. With all three carbs open (progressive linkage) the choke plates would suck closed a bit (471 blower) on carbs 1 & 3 and as a result the fast idle cams would create a 1300 PRM idle at the next stop light until I got out and pulled it back manually. I asked Clive @ Stromberg how to remedy and he sent me these
    Simply remove the large fulcrum bolt, pull the detent and spring out of the carb and inset this little piece.
    All you have to do is remove the detent pin and spring pictured here
    and install the new lock out pin $7.50 @ summit Racing
    It engages the holes in the linkage and locks out the choke in minutes. Now only my center carb has a functioning choke on a cable to the dash and I don't have to worry about the outer two hanging up any longer.

    Hope it helps.

    dana barlow, GordonC, Stebo27 and 7 others like this.
  24. jailbar joe
    Joined: Nov 21, 2014
    Posts: 322

    jailbar joe
    Member

    no need to justify... your car your way

    Moriarity likes this.
  25. 1low52
    Joined: Oct 26, 2007
    Posts: 286

    1low52
    Member

    Wow!
    Just came across this thread! Pure Porn!!!

    Here is my humble contribution. 20180518_141305.jpg

    wraymen, TBirdGirl26, Stebo27 and 9 others like this.
  26. seabeecmc
    Joined: Jan 28, 2005
    Posts: 987

    seabeecmc
    ALLIANCE MEMBER

  27. Ford Y-block


    Attached Files:

  28. Gary in MN
    Joined: Jun 27, 2008
    Posts: 120

    Gary in MN
    Member

    Model A Ford , 4 Stromberg 97's two for show and two for go. Gary in MN DSC00652 (300x169) (2).jpg

  29. RACE ROD
    Joined: Sep 17, 2005
    Posts: 82

    RACE ROD
    Member
